flat enameled copper magnet wire
Touch screen plays an important role in modern society, it is common in devices such as .game consoles, personal computers, tablet computers, electronic voting machines, point of sale systems, and smartphones They can also be attached to computers or, as terminals, to networks. They also play a prominent role in the design of digital appliances such as personal digital assistants (PDAs) and somee-readers.
Our enamelled wire has been widedly used in different types of touch screen, and it’s been proved great quality and high stabiliy
Features and benefits:
1.Very good solderability that can be soldered without removal of coating.
2.Superior “Q” characteristics at high frequencies.
3. Proved high quality and stability
Certificates:
ISO 9001-2000, ISO TS 16949, ISO 14001-2004,
UL Approved, RoHS Directive Met
Executive standards
IEC, JIS and NEMA.
Technical specifications:
| Nominal Diameter mm |
Tolerance mm |
Min. Increase of Diameter | Max. Overall Diameter |
Breakdown Voltage ≥ V |
Elongation ≥% |
Pin Hole ≤Default/5m |
Electrical Resistance Ω/km (20℃) |
||
| Mandrel Method | Twisted Method | Min. | Max. | ||||||
| 0.012 | —- | 0.013 | 0.015 | 50 | —- | 5 | 10 | 142.64 | 157.65 |
| 0.013 | —- | 0.015 | 0.017 | 70 | —- | 5 | 10 | 118.41 | 133.98 |
| 0.014 | —- | 0.016 | 0.018 | 70 | —- | 5 | 10 | 102.64 | 120.45 |
| 0.015 | —- | 0.017 | 0.020 | 80 | —- | 5 | 10 | 89.83 | 104.41 |
| 0.016 | —- | 0.018 | 0.021 | 90 | —- | 5 | 8 | 74.67 | 97.56 |
| 0.017 | —- | 0.019 | 0.022 | 90 | —- | 5 | 8 | 66.60 | 85.75 |
| 0.018 | —- | 0.020 | 0.023 | 100 | —- | 5 | 8 | 59.77 | 75.95 |
| 0.019 | —- | 0.021 | 0.024 | 100 | —- | 5 | 8 | 53.95 | 67.75 |
| 0.020 | 0.002 | 0.022 | 0.024 | 100 | —- | 5 | 8 | ||
